Ročne

Junior + G

Tehnični podatki
Model
Phoenix	2450x27x0,9 mm	35-70 m/1'		1.1 HP, 0.3 KW	840mm	700x1500x1500	205

Rezalne kapacitete

0°	220 mm		210 mm	120x250 mm		215x230 mm
45° -->	150 mm		145 mm	145x145 mm		200x135 mm
60° -->	90 mm		85mm	85x85 mm		85x80 mm

Phoenix

Tehnični podatki
Model
Phoenix	2450x27x0,9 mm	35-70 m/1'		1.0 HP, 0.75 KW	985 mm	800x1350x1600	268
Phoenix+V	2450x27x0,9 mm	20+100 m/1'		1.5 HP, 1.1 KW	985 mm	800x1350x1600	268
Rezalne kapacitete

0°	220 mm		21 mm	130x250 mm		215x230 mm
45° -->	150 mm		150 mm	150x150 mm		200x135 mm
60° -->	90 mm		90 mm	90x90 mm		90x90 mm

Triton

Tehnični podatki
Model
Triton	2700x27x0,9 mm	35-70 m/1'		1.7 HP, 1.3 KW	985 mm	900x1450x1600	286
Triton+V	2700x27x0,9 mm	20+100 m/1'		1.5 HP, 1.1 KW	985 mm	900x1450x1600	286
Rezalne kapacitete

0°	240 mm		240 mm	210x280 mm		240x260 mm
45° -->	185 mm		175 mm	140x180 mm		220x165 mm
60° -->	115 mm		110 mm	110x110 mm		110x110 mm

Antares

Tehnični podatki
Model
Antares	2700x27x0,9 mm	35-70 m/1'		1.7 HP, 1.3 KW	960 mm	900x1450x1600	334
Antares+V	2700x27x0,9 mm	20+100 m/1'		1.5 HP, 1.1 KW	960 mm	900x1450x1600	334
Rezalne kapacitete

0°	200 mm		200 mm	200x200 mm		240x200 mm
45° -->	180 mm		175 mm	135x180 mm		200x140 mm
60° -->	100 mm		100 mm	105x105 mm		105x105 mm
45°< --	140 mm		135 mm	125x145 mm		170x105 mm
60° <--

Orion

Tehnični podatki
Model
Orion	2700x27x0,9 mm	35-70 m/1'		1.7 HP, 1.3 KW	990 mm	900x1450x1600	424
Orion + V	2700x27x0,9 mm	20+100 m/1'		1.5 HP, 1.1 KW	990 mm	900x1450x1600	424
Rezalne kapacitete

0°	240 mm		240 mm	200x310 mm		240x270 mm
45° -->	175 mm		170 mm	170x170 mm		240x155 mm
60° -->	110 mm		105 mm	105x105 mm		140x100 mm
45°< --	150 mm		135 mm	125x145 mm		240x65 mm
60° <--

Titan G

Tehnični podatki
Model
Titan	3300x27x0,9 mm	35-70 m/1'		1.7 HP, 1.3 KW	960 mm	900x1800x1600	456
Titan+V	3300x27x0,9 mm	20+100 m/1'		1.5 HP, 1.1 KW	960 mm	900x1800x1600	456
Rezalne kapacitete

0°	260 mm		260 mm	260x370 mm		260x370 mm
45° -->	260 mm		260 mm	120x290 mm		260x260 mm
60° -->	180 mm		180 mm	90x190 mm		180x180 mm

Mercury G

Tehnični podatki
Model
Mercury + G	3200x27x0,9 mm	35-70 m/1'		1.73 HP, 1.33 KW	960 mm	1000x170x1600	640
Mercury + G + VHZ	3200x27x0,9 mm	16+100 m/1'		2 HP, 1.5 KW	960 mm	1000x1700x1600	640
Rezalne kapacitete

0°	305 mm		300 mm	300x370 mm		300x370 mm
45° -->	260 mm		240 mm	155x260 mm		300x220 mm
60° -->	170 mm		160 mm	160x170 mm		255x150 mm

Saturn G

Tehnični podatki
Model
Saturn	3420x27x0,9 mm	35-70 m/1'		1.73 HP, 1.33 KW	990 mm	1000x1600x1600	770
Saturn+V	3420x27x0,9 mm	16+100 m/1'		2 HP, 1.5 KW	990 mm	1000x1600x1600	770
Rezalne kapacitete

0°	305 mm		300 mm	300x375 mm		300x375 mm
45° -->	260 mm		240 mm	155x260 mm		300x220 mm
60° -->	170 mm		160 mm	160x170 mm		265x150 mm
45°< --	280 mm		255 mm	180x1+280 mm		300x245 mm
60° <--

Pegasus G + VHZ

Tehnični podatki
Model
Pegasus + G + VHZ	4120x34x1,1 mm	16-120 m/1'		4.0 HP, 3.0 KW	760 mm	1400x2100x1600	760
Rezalne kapacitete

0°	330 mm		330 mm	330x330 mm		330x510 mm
45° -->	330 mm		330 mm	190x360 mm		330x330 mm
60° -->	240 mm		160 mm	160x230 mm		160x230 mm

OSTALE PRODUKTE SI LAHKO OGLEDATE V PDF KATALOGU

POVPRAŠEVANJE
